Description
The Doppler Fetal Monitor YR02180 is an advanced patient monitoring device designed for use in operating theaters and intensive care units. This versatile monitor features a 17-inch LCD screen and supports semi-modular parameter configurations, including standard measurements like ECG, SPO2, TEMP, NIBP, RESP, and PR/HR. It provides a range of options for specific monitoring needs, such as 5-lead ECG, RESP, Dual-Temp, SpO2, and NIBP, with extra options available for touch screens, Masimo/Nellcor SpO2, and more.
Market Price
The market price for high-quality fetal monitor systems like the Doppler Fetal Monitor YR02180 generally ranges between 3500 USD and 4300 USD. This range reflects the advanced technology and reliability that healthcare professionals expect from premium monitoring systems.
Frequently Asked Questions
Q: Can the monitor be upgraded with additional features?
A: Yes, the Doppler Fetal Monitor YR02180 offers optional add-ons like touch screens, Nellcor SpO2, and thermal recorders for tailored functionality.
Q: Is this monitor suitable for both adult and neonatal care?
A: Absolutely, this monitor is designed to handle a wide range of patient needs, from adult to pediatric care.
Advantages and Disadvantages
One of the major advantages of the Doppler Fetal Monitor YR02180 is its versatility, allowing for customization based on specific clinical requirements. It offers precise readings with high accuracy across various parameters. However, due to its advanced features and capabilities, it may come with a steep learning curve for some users.
Product Use in the Field
In practical settings, the Doppler Fetal Monitor YR02180 is implemented in both intensive care units and operating theaters. Its robust build and reliable readings make it an essential tool for continuous patient monitoring, ensuring optimal patient care and intervention when necessary.
Recommendations
For optimal performance and longevity of the Doppler Fetal Monitor YR02180, regular maintenance and calibration are recommended. Utilize the platform Kalstein Plus to generate an automatic quotation and order with efficiency and ease.
Features
- 17-inch LCD display for clear visibility.
- Supports semi-modular parameter configurations.
- Standard configuration includes ECG, RESP, Dual-Temp, SpO2, NIBP monitoring.
- Optional upgrades for specific clinical needs.
Technical Specifications
| Model | YR02180 | |
|
ECG
|
Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
|
Heart Rate
|
Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
|
Respiration
|
Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
|
NIBP
|
Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
|
SPO2
|
Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
|
TEMP
|
Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
