Description
The Small Sized Storage Series (Square Racks) YR05371 // YR05382 is a versatile and efficient solution for laboratories that require low LN₂ consumption and high storage capacity. Designed to store between 600 to 1100 vials in square racks and cryo boxes, this storage series is equipped with a dual handle design and offers advanced thermal efficiency. Its lightweight and durable construction makes it suitable for a wide array of lab applications, ensuring maximum cryogenic storage efficiency with minimal footprint.
Market Price
For those looking to invest in reliable cryogenic storage, products like the Small Sized Storage Series are priced competitively in the market. While individual prices can vary, such high-performance storage systems typically range from $500 to $800, depending on specific features and additional accessories included.
Frequently Asked Questions
- What is the warranty period for this storage series? The product comes with a 5-year vacuum warranty for peace of mind.
- Does the device require any special maintenance? Regular inspections for wear and ensuring the seal integrity can help maintain optimal performance.
- Is temperature monitoring included? Yes, temperature monitoring is available with this series.
Advantages and Disadvantages
Advantages: The storage series offers low LN₂ evaporation loss, superior insulation, and high thermal efficiency. It’s lightweight and features a secure, lockable enclosure.
Disadvantages: Some models may not include a protective jacket or roller base as standard, which are optional accessories.
Product Usage in the Field
This storage series is ideally used in laboratory settings where space efficiency and storage capacity are critical. Laboratories handling various cryogenic processes can leverage this product to store biological samples safely.
Recommendations
To maximize the longevity and effectiveness of the Small Sized Storage Series, it is recommended to avoid exposing the unit to extreme temperatures or physical impacts. Always follow the manufacturer’s guidelines for filling and storage procedures.
Features
- 5 Year Vacuum Warranty
- High Thermal Efficiency
- Lightweight
- 30 Litre to 50 Litre Capacity
- Durable and Secure
- Super-Insulation
- Ideal for Lab Applications
- Heavy duty lockable enclosure for enhanced security
Technical Specifications
| Model | YR05371 | YR05372 | YR05373 | YR05374 | ||||
| Maximum Storage Capacity | ||||||||
| No. of Rack | 1 | 6 | ||||||
| 1.2&2 ml Cryovials (25 per box) | 100 | 600 | ||||||
| No. of Boxes in ( Rack) | 4 | 4 | ||||||
| Performance | ||||||||
| Volume of LN₂ (L) | 10 | 31.5 | ||||||
| Static Evapouration* (L/Day) | 0.42 | 0.35 | ||||||
| Static Holding Time** (Day) | 24 | 90 | ||||||
| Dimensions | ||||||||
| Opening Diameter (mm) | 125 | 125 | ||||||
| Height (mm) | 625 | 704 | ||||||
| Outside Diameter (mm) | 300 | 462 | ||||||
| Empty Weight (kg) | 6.3 | 13 | ||||||
| Full Weight (kg) | 15.1 | 38.9 | ||||||
| Shipping Weight (kg) | 9.6 | 19.3 | ||||||
| Aditional Features | No canister; no protective jacket;
no lockable cap; equipped with braces for carrying |
Include 1 square rack with
4 layers and 5*5 cryobox; lockable cap; no protective jacket |
Includes 6 racks with 4 layers,
5*5 cryoboxes, lockable cap and protective jacket, roller base is optional. |
Includes protective
jacket only, roller base is optional |
||||
| Model | YR05375 | YR05376 | YR05377 | YR05378 | YR05379 | YR05380 | YR05381 | YR05382 |
| Maximum Storage Capacity | ||||||||
| No. of Rack | 6 | 6 | 6 | |||||
| 1.2&2 ml Cryovials (25 per box) | 750 | 1110 | 900 | |||||
| No. of Boxes in ( Rack) | 5 | 5 | 6 | |||||
| Performance | ||||||||
| Volume of LN₂ (L) | 35.5 | 47 | 50 | |||||
| Static Evapouration* (L/Day) | 0.36 | 0.36 | 0.45 | |||||
| Static Holding Time** (Day) | 97 | 130 | 110 | |||||
| Dimensions | ||||||||
| Opening Diameter (mm) | 125 | 127 | 125 | |||||
| Height (mm) | 748 | 718 | 818 | |||||
| Outside Diameter (mm) | 462 | 508 | 462 | |||||
| Empty Weight (kg) | 14.5 | 18.2 | 17.3 | |||||
| Full Weight (kg) | 43.2 | 60.9 | 62.4 | |||||
| Shipping Weight (kg) | 21.9 | 30.7 | 30.3 | |||||
| Aditional Features | Includes 6 canisters (height 276mm),
lockable cap and protective jacket, roller base is optional |
Includes 6 racks with 5 layers,
5*5 cryoboxes, lockable cap and protective jacket, roller base is optional. |
Includes protective jacket
only, roller base is optional |
Includes 6 round rack with
5 layers (37 holes) and lockable cap, no protective jacket, roller base is optional |
Includes 10 canisters
(Φ72 / 276mm) and lockable cap, no protective jacket, roller base is optional |
Includes 6 racks with 6 layers,
5*5 cryoboxes, lockable cap and protective jacket, roller base is optional. |
Includes 6 canisters
(Φ97 / 276mm), lockable cap and protective jacket. roller base is optional |
Includes protective
jacket only, roller base is optional |
